Removal and Installation

REMOVAL
INSTALLATION
Installation is in the reverse order of removal.
Rear door speaker
Bose speaker ampFront wiper auto stop signal circuit
Component Function Check
1. CHECK FRONT WIPER (AUTO STOP) OPERATION
CONSULT DATA MONITOR
Select "WIP AUTO STOP" of IPDM E/R DATA MONITOR item.
Operate the front wiper.
With the front wiper operation, check the monitor status.
Diagnosis Procedure
1. CHECK IPDM E/R OUTPUT VOLTAGE
...
Unit removal and installation
Rear suspension assembly
Exploded View
Rear shock absorber cap
Strut mount insulator
Shock absorber mount seal
Rear suspension bound bumper
Rear shock absorber
Rear suspension arm
Connecting rod mount bracket
Rear stabilizer connecting rod
Rear spring upper rubber seat ...
Front door glass
Exploded View
Door panel
Door glass
Regulator assembly
Door module assembly
Window motor
Removal and Installation
REMOVAL
Remove the front door finisher. Refer to INT-18, "Removal and
Installation".
Remove the adhesive bolt hole covers.
Reconnect the window switch to ...
