Component Function Check
Symptom
INSPECTION FLOW
Low tire pressure warning lamp does not turn on
Low Tire Pressure Warning Lamp Does Not Come On When Ignition Switch
Is Turned On
NOTE: The Signal Tech II Tool (J-50190) can be used
to perform the following functions. Refer to the Signal Tech II User Guide
for additional information.
Activate and display TPMS transmitter IDs
&n ...
Diagnosis and repair work flow
Work Flow
OVERALL SEQUENCE
DETAILED WORK FLOW
1.CUSTOMER INFORMATION
Get detailed information from the customer about the symptom.
2.PRELIMINARY CHECK
Perform preliminary check.
3.TECHNICAL SERVICE BULLETINS
Check for technical service bulletins.
4.USER MODE
Perform self-diagnosis usin ...
TPMS
System Diagram
System Description
DESCRIPTION
During driving, the tire pressure monitoring system receives the signal
transmitted from the transmitter installed in each wheel, and turns on the
low tire pressure warning lamp when the tire pressure becomes low.
The
control unit (BCM) for t ...
